EPS

Update:：2015-06-08 16:05 View：

EPS Specification:

Classification	Spec.	Diam Range(mm)	Times	Density(g/l)	Blowing Agent(%)	Residual SM(ppm)	Moisture(%)	Coating Agent(ppm)	Oxygen Index.(%)
E General Grade	E-301	1.00~1.60	70~85	12~14	6.5-7.2	≤4000	≤1.0%	≤3200	N.A
	E-302	0.85~1.25	60~70	14~16
	E-303	0.70~0.90	55~65	15~18
	E-401	0.50~0.80	40~55	18~25
	E-501	0.40~0.60	30~40	25~30
P Multiple-Times Grade	P-301	1.00~1.60	75~90	11~13	6.5-7.5	≤5000	≤1.0%	≤3200	N.A
	P-302	0.85~1.25	65~75	13~15
	P-303	0.70~0.90	55~70	14~18
	P-401	0.50~0.80	45~55	18~20
	P-501	0.40~0.60	40~50	20~25
F FlameRetardant Grade	F-301	1.00~1.60	70~85	12~14	6.2-7.3	≤2000	≤2.0%	≤3200	≥30
	F-302	0.85~1.25	60~70	14~16
	F-303	0.70~0.90	50~65	15~18
	F-401	0.50~0.80	40~50	18~25
	F-501	0.40~0.60	30~45	25~30
B Instant Grade	B-301	1.00~1.60	55~70	14~18	5.5-6.8	≤2000	≤1.0%	≤3200	N.A
	B-302	0.85~1.25	50~60	16~20
	B-303	0.70~0.90	40~55	18~25
	B-401	0.50~0.80	35~45	22~30
	B-501	0.40~0.60	30~40	25~35
L Low Pentane Grade	L-301	1.00~1.60	40~60	16~25	4.5-5.5	≤2000	≤2.0%	≤3200	≥30(F)
	L-302	0.85~1.25	40~50	20~25
	L-303	0.70~0.90	35~45	22~28
	L-401	0.50~0.80	30~40	25~33
	L-501	0.40~0.60	30~35	28~33
HF Gaphite Grade	HF-301	1.00~1.60	55~70	14~18	5.5-6.8	≤2000	≤2.0%	≤3200	≥30
	HF-302	0.85~1.25	50~60	16~20
	HF-303	0.70~0.90	40~55	18~25
	HF-401	0.50~0.80	35~45	22~30
	HF-501	0.40~0.60	30~40	25~35
NOTE	Foam density≥18（kg/m³）;Thermal conductivity≤0.034w/mK; Flame retardant: Class B or C(According to GB8624-2006) This company can produce the special materials according to the special requirements of clients.
